Connectivity

Signal Input

• VGA (Analog )
• DisplayPort x 1
• HDMI (digital, HDCP)

Sync Input

• Separate Sync
• Sync on Green

Audio (In/Out)

HDMI audio out

Picture/Display

Panel Size

27 inch / 68.6 cm

Aspect ratio

16:9

LCD panel type

IPS technology

Backlight type

W-LED system

Pixel pitch

0.233 x 0.233 mm

Brightness

350  cd/m²

Display colors

16.7 M

Color gamut (typical)

NTSC 114%*, sRGB 131%*

Contrast ratio (typical)

1000:1

SmartContrast

Mega Infinity DCR

Response time (typical)

4 ms (Gray to Gray)*

Viewing angle

• 178º (H) / 178º (V)
• @ C/R > 10

Picture enhancement

SmartImage game

Maximum resolution

2560 x 1440 @ 75 Hz*

Effective viewing area

596.7 (H) x 335.7 (V)

Scanning Frequency

30 - 85 kHz (H) / 48 - 76 Hz (V)

sRGB

Yes

Flicker-free

Yes

Pixel Density

109 PPI

LowBlue Mode

Yes

Display Screen Coating

Anti-Glare, 3H, Haze 25%

AMD FreeSync™ technology

Yes

Convenience

Plug & Play Compatibility

• DDC/CI
• Mac OS X
• sRGB
• Windows 10 / 8.1 / 8 / 7

User convenience

• Power On/Off
• Menu
• Brightness
• Input
• SmartImage Game

OSD Languages

• Brazil Portuguese
• Czech
• Dutch
• English
• Finnish
• French
• German
• Greek
• Hungarian
• Italian
• Japanese
• Korean
• Polish
• Portuguese
• Russian
• Simplified Chinese
• Spanish
• Swedish
• Traditional Chinese
• Turkish
• Ukrainian

Other convenience

• Kensington lock
• VESA mount (100x100mm)

Stand

Tilt

-5/20  degree

Power

Power supply

• External
• 100-240VAC, 50-60Hz

Off mode

< 0.3 W (typ.)

On mode

29.75 W (typ.)

Standby mode

< 0.5 W (typ.)

Power LED indicator

• Operation - White
• Standby mode- White (blinking)

Dimensions

Product with stand (mm)

610 x 455 x 176  mm

Packaging in mm (WxHxD)

670 x 520 x 142  mm

Product without stand (mm)

610 x 363 x 35  mm

Weight

Product with packaging (kg)

5.83  kg

Product with stand (kg)

4.05  kg

Product without stand (kg)

3.57  kg

Operating conditions

Altitude

Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)

Temperature range (operation)

0 to 40  °C

MTBF

50,000 hrs (excluding backlight)  hour(s)

Relative humidity

20%-80  %

Temperature range (storage)

-20 to 60  °C

Sustainability

Environmental and energy

RoHS

Recyclable packaging material

100  %

Specific Substances

• Mercury free
• PVC / BFR free housing

Compliance and standards

Regulatory Approvals

• CCC
• CECP
• CEL

Cabinet

Color

Black / Gunmetal

Finish

Glossy
