Picture/Display I

Panel Size

23.8 inch / 60.5 cm

Monitor Panel Type

IPS technology

Brightness

250  cd/m²

Contrast ratio (typical)

1000:1

SmartContrast

50,000,000:1

Display colors

16.7 M (6 bit + Hi FRC)

Color gamut (typical)

NTSC 99%*, sRGB 99.8%*

Aspect ratio

16:9

Backlight type

W-LED system

Display Screen Coating

Anti-Glare, 3H, Haze 25%

EasyRead

Yes

Effective viewing area

526.848 (H) x 296.352 (V) mm

Flicker-free

Yes

LowBlue Mode

Yes

Maximum resolution

2560 x 1440 @ 75 Hz*

Picture enhancement

SmartImage

Pixel Density

123 PPI

Pixel pitch

0.2058 x 0.2058 mm

Scanning Frequency

30 - 114 kHz (H) / 48 - 75 Hz (V)

sRGB

Yes

Viewing angle

178º (H) / 178º (V), @ C/R > 10

Response time (typical)

4 ms (Gray to Gray)*

Picture/Display II

Panel Size

13.3 inch / 33.8 cm

Monitor Panel Type

EPD

Aspect ratio

3:4

Display colors

4 bits grey scale

Display Screen Coating

Anti-Glare, 3H, Haze 15%

Effective viewing area

278.4 (H) x 202.8 (V) mm

Optimum resolution

1200 x 1600

Pixel Density

150 PPI

Pixel pitch

0.169 x 0.169 mm

Connectivity/Display I

Audio (In/Out)

Audio out

HDCP

HDCP 1.4 (DisplayPort / USB-C)

RJ45

Ethernet LAN up to 1G*, Wake on LAN

Signal Input

DisplayPort 1.2 x 1, USB-C x 1 (DP Alt mode, Power delivery)

Sync Input

Separate Sync

USB Hub

USB 3.2 Gen 2 / 10 Gbps, USB-C upstream x 1, USB-A downstream x 4 (with 1 fast charge B.C 1.2)

Connectivity/Display II

Audio (In/Out)

Audio out

HDCP

HDCP 1.4 (USB-C)

Signal Input

USB-C x 1 (DP Alt Mode, Power delivery)

Sync Input

Separate Sync

Power Delivery/Display I

Max power delivery

USB-C up to 90W (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/4.5A)

Version

USB PD version 3.0

Power Delivery/Display II

USB-C (input)

65W (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/3.25A)

USB-C (output)

15W (5V/3A)

Version

USB PD version 3.0

Convenience/Display I

OSD Languages

• Brazil Portuguese
• Czech
• Dutch
• English
• Finnish
• French
• German
• Greek
• Hungarian
• Italian
• Japanese
• Korean
• Polish
• Portuguese
• Russian
• Simplified Chinese
• Spanish
• Swedish
• Traditional Chinese
• Turkish
• Ukrainian

Other convenience

Kensington lock, VESA mount (100x100mm)

Plug & Play Compatibility

DDC/CI, Mac OS X, sRGB, Windows 11 / 10 / 8,1 / 8 / 7

User convenience

SmartImage, Input, Brightness, Menu, Power On/Off

Control software

SmartControl

Convenience/Display II

Other convenience

Kensington lock, VESA mount (100x100mm), Front Light (White/Yellow)

User convenience

Clear, Front light, Mode, Level, Menu/Power

OSD Languages

• Brazil Portuguese
• Czech
• Dutch
• English
• Finnish
• French
• German
• Greek
• Hungarian
• Italian
• Japanese
• Korean
• Polish
• Portuguese
• Russian
• Simplified Chinese
• Spanish
• Swedish
• Traditional Chinese
• Turkish
• Ukrainian

Plug & Play Compatibility

DDC/CI, Mac OS X, sRGB, Windows 11 / 10 / 8,1 / 8 / 7

Stand

Height adjustment

100  mm

Swivel

-/+45  degree

Tilt

-5/23  degree

Power

ECO mode

18.5 W (typ.)

Power supply

• External
• 100-240VAC, 50-60Hz

Off mode

0.3 W (typ.)

On mode

26 W (typ.)

Standby mode

0.3 W (typ.)

Power LED indicator

• Operation - White
• Standby mode- White (blinking)

Dimensions

Packaging in mm (WxHxD)

980 x 420 x 159  mm

Product without stand (mm)

787 x 323 x 46  mm

Product with stand(max height)

787 x 453 x 239  mm

Weight

Product with packaging (kg)

10.63  kg

Product with stand (kg)

6.19  kg

Product without stand (kg)

4.86  kg

Operating conditions

Altitude

Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)

Temperature range (operation)

0°C to 40  °C

Relative humidity

20%-80  %

Temperature range (storage)

-20°C to 60  °C

MTBF (demonstrated)

Display 1: 70,000 hrs (excluded backlight)

Sustainability

Environmental and energy

RoHS

Post consumer recycled plastic

85%

Recyclable packaging material

100  %

Specific Substances

• Mercury free
• PVC / BFR free housing

Compliance and standards

Regulatory Approvals

• CB
• CCC
• CE Mark
• FCC Class B
• ICES-003

Cabinet

Finish

Texture

Foot

Black

Front bezel

Black

Rear cover

Black
