Connectivity

Signal Input

• VGA (Analog )
• DisplayPort x 1
• HDMI (digital, HDCP)

Sync Input

• Separate Sync
• Sync on Green

Audio (In/Out)

• PC audio-in
• Headphone out

Picture/Display

Panel Size

23.8 inch / 60.5 cm

Aspect ratio

16:9

LCD panel type

IPS technology

Backlight type

W-LED system

Pixel pitch

0.2745 x 0.2745 mm

Brightness

300  cd/m²

Display colors

16.7 M

Color gamut (typical)

NTSC 97.4%*, sRGB 113.8%*

Contrast ratio (typical)

1000:1

SmartContrast

Mega Infinity DCR

Response time (typical)

4 ms (Grey to Grey)*

Viewing angle

• 178º (H) / 178º (V)
• @ C/R > 10

Picture enhancement

SmartImage game

Maximum resolution

1920 x 1080 @ 75 Hz*

Effective viewing area

527.04 (H) x 296.46 (V) mm

Scanning Frequency

30 - 85 kHz (H) / 48 - 75 Hz (V)

sRGB

Yes

Flicker-free

Yes

Pixel Density

93 PPI

LowBlue Mode

Yes

Display Screen Coating

Anti-Glare, 3H, Haze 25%

MPRT

1 ms

EasyRead

Yes

AMD FreeSync™ technology

Yes

Convenience

Built-in Speakers

3 W x 2

Plug & Play Compatibility

• DDC/CI
• Mac OS X
• sRGB
• Windows 10 / 8.1 / 8 / 7

User convenience

• Power On/Off
• Menu
• Volume
• Input
• SmartImage Game

OSD Languages

• Brazil Portuguese
• Czech
• Dutch
• English
• Finnish
• French
• German
• Greek
• Hungarian
• Italian
• Japanese
• Korean
• Polish
• Portuguese
• Russian
• Simplified Chinese
• Spanish
• Swedish
• Traditional Chinese
• Turkish
• Ukrainian

Other convenience

• Kensington lock
• VESA mount (75x75mm)

Stand

Tilt

-5/20  degree

Power

Power supply

• External
• 100-240VAC, 50-60Hz

Off mode

0.3 W

On mode

12.19 W (typ.) (EnergyStar test method)

Standby mode

0.5 W

Power LED indicator

• Operation - White
• Standby mode- White (blinking)

Dimensions

Packaging in mm (WxHxD)

595 x 449 x 153  mm

Product without stand (mm)

540 x 312 x 36  mm

Product with stand(max height)

540 x 428 x 187  mm

Weight

Product with packaging (kg)

5.25  kg

Product with stand (kg)

3.45  kg

Product without stand (kg)

2.28  kg

Operating conditions

Altitude

Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)

Temperature range (operation)

0 to 40  °C

MTBF

50,000 hrs (excluding backlight)  hour(s)

Relative humidity

20%-80  %

Temperature range (storage)

-20 to 60  °C

Sustainability

Environmental and energy

• EnergyStar 8.0
• TCO Certified
• RoHS
• Mercury Free

Recyclable packaging material

100  %

Compliance and standards

Regulatory Approvals

• CB
• TUV/ISO9241-307
• TUV-BAUART
• CU-EAC
• EAEU RoHS
• CE Mark
• FCC Class B
• ICES-003

Cabinet

Color

Black

Finish

Textured
